Safety Thermostat Fixed 230C Manual Reset High-Temperature Cut-Out

The Tecasa SP-011 GF is a safety thermostat (also known as a thermal cut-out) designed to protect equipment from overheating. It features a fixed temperature limit of 230C and a manual reset function, ensuring that the system must be checked and reset by an operator after a thermal fault occurs.

This type of thermostat is typically used as a safety backup in high-temperature appliances, shutting off the circuit when the maximum temperature is exceeded.

Technical Specifications:

• Model: SP-011 GF

• Function: Safety thermostat / thermal cut-out

• Fixed Trip Temperature: 230C

• Reset Type: Manual reset (non-automatic)

• Switch Type: Single-pole, Normally Closed (opens on temperature rise)

• Max Load: 16A at 250V~

• Body Material: High-temperature resistant housing
